Guides left, guides right. Even where others only pretend to do so. With spherical bushings on both sides to offer a double layer of protection in terms of keeping the carriage precisely on course across extra-large columns. Double-sealed for an extremely long service life, always exact and with zero play.
Includes; HW 260×2,5×30 W60 Saw blade, Bevel SM-KS, Hex Key WAF 6, Terminal KL-KS 120.
| Power Consumption: | 1600W |
|---|---|
| Idle Engine Speed: | 1400-3600 min |
| Diametre of Saw Blade: | 260mm |
| Cutting Depth 90°/90°: | 305 x 88mm |
| Cutting Depth 45°/90°: | 215 x 88mm |
| Special cutting depth 90°/90°: | 60 x 120mm |
| Crown moulding diagonal cut 45°/90°: | 160mm |
| Inclination Angle: | 47/47 ° |
| Mitre Angle: | 50/60 ° |
| Dimensions (W x D x H): | 713 x 500 x 470 mm |
| Cable length: | 3.5m |
| Dust extraction connection diameter: | 27/36mm |
| Special cut. depth 45°/90° (left): | 40 x 120 mm |
| Special cutting depth 45°/90° (right): | 20 x 120 mm |
| Cutting depth 50°/90° (left): | 196 x 88 mm |
| Cutting depth 60°/90° (right): | 152 x 88 mm |
| Cutting depth 45°/45° (left): | 215 x 55 mm |
| Cutting depth 45°/45° (right): | 215 x 35 mm |
| Crown moulding diagonal cut at 90°/90°: | 160mm |
| Work Height: | 900mm |
